Regular price $14,990.00

Unit price per

Style

The Ironwood CUT24 cut-off saw offers operators a safe and reliable, compact crosscutting solution.  The table surface of the CUT24 saw is precision ground to ensure absolute cutting accuracy while maintaining maximum stability during heavy cutting operations. The pneumatically operated machine highlights enhanced safety guards, fast cutting speeds, and the powerful motor torque required when working with multiple material types and dimensions.

  • Cutting capacities offer maximum thickness up to 8” and up to 21” width
  • Table surface is precision ground to assure cutting accuracy
  • Powerful, high torque 15 HP motor drive ensure high stability at fast cutting speeds
  • Belt-tension adjustments and replacements are performed quick and easy
  • Ironwood’s optional outfeed roller conveyor can be equipped with a graduated gauge bar and flip stops to ensure consistent cutting lengths
  • Pneumatic operation of the cutting cycle is conveniently controlled via foot pedal
  • Pressure clamp is easily adjusted to provide versatility when working with varying thicknesses of material
  • Proper dust ports ensure positive air flow to prevent dust build-up within the machine cabinet
  • Cycle speeds can be conveniently adjusted from outside the machine cabinet
  • Adjustable saw stroke from front of machine for faster cycle times
  • Machines are offered in right-handed feed and left-handed feed directions
  • Safety guard minimizes risk of operator’s hand accessing the cutting area
  • Enhanced safety elements ensure saw blade is totally enclosed within the cabinet and covered by the pressure clamp when raised to perform cutting operation
  • Limit switches ensure safe tool changes, allowing access doors to opened only when blade has stopped rotating
  • Emergency Stop
  • Conforms to UL electric standards
  • Six Month electrical warranty
  • One year mechanical warranty
Cutting capacity (thickness x width) 2” x 21”/ 4” x 19” / 6” x 15” / 8” x 8”
Cycle operation Pneumatic
Material Feed Direction RH or LH
Saw blade size 20” / 22” / 24” (standard)
Saw arbor Ø 1”
Saw blade speed 2400 RPM
Table size 26” x 45 ¼”
Working table height 34 ¼”
Motor 15 HP IE3
Dust port Ø / CFM 2 x 4” / 900 CFM
Air pressure 80-90 PSI
Air consumption 12 CFM at 45 CPM
Gross weight 1,240 lbs.
Packing Dimensions 53 ½” x 35 ½” x 57”
Electrical Connection* 230 Volts | 3-phase | 60 Hz.

   *460V power upgrades available upon request.  Additional charges may apply.
